Hackery Overcloud Ceph Deployment RDO Mitaka via TripleO QuickStart

I believe that similar procedure would work for RDO Newton  when conversion
to routable "ctlplane" will be completed. To avoid hitting "OSDs fewer than Replicas" corresponding tripleo-heat-template get discovered and updated before running overcloud deployment. In meantime "ctlplane" is converted to
192.168.24.0/24 and br-ctlplane has IP 192.168.24.1 on both Mitaka and Newton.Changes bellow obviously were done only due to limited hardware ,
e.g. 4 Core CPU.

***************************************************************
Hack before runnng overcloud-deploy.sh
First find template with entry  "osd_pool_default_size"
***************************************************************

[root@undercloud openstack-tripleo-heat-templates]# cat search.sh
for W in `find . -name "ceph*.yaml" -print`
do
echo $W
cat $W | grep "osd_pool_default_size"
done

***********************
Current directory
***********************
/usr/share/openstack-tripleo-heat-templates

[root@undercloud openstack-tripleo-heat-templates]# ./search.sh
./network/config/bond-with-vlans/ceph-storage.yaml
./network/config/multiple-nics/ceph-storage.yaml
./network/config/single-nic-linux-bridge-vlans/ceph-storage.yaml
./network/config/single-nic-vlans/ceph-storage.yaml
./puppet/ceph-cluster-config.yaml
./puppet/ceph-storage-post.yaml
./puppet/ceph-storage.yaml
./puppet/extraconfig/ceph/ceph-external-config.yaml
./puppet/hieradata/ceph.yaml
ceph::profile::params::osd_pool_default_size: 3

*****************************************************************************************
Update /usr/share/openstack-tripleo-heat-templates/puppet/hieradata/ceph.yaml
*****************************************************************************************
ceph::profile::params::osd_pool_default_size: 2

******************
Create file
******************

[stack@undercloud ~]$ cat $HOME/network_env.yaml
{
    "parameter_defaults": {
        "ControlPlaneDefaultRoute": "192.168.24.1",
        "ControlPlaneSubnetCidr": "24",
        "DnsServers": [
            "192.168.23.27"
        ],
        "EC2MetadataIp": "192.168.24.1",
        "ExternalAllocationPools": [
            {
                "end": "10.0.0.250",
                "start": "10.0.0.4"
            }
        ],
        "ExternalNetCidr": "10.0.0.1/24",
        "NeutronExternalNetworkBridge": ""
    }
}

************************
Run deployment
************************
#!/bin/bash -x
source /home/stack/stackrc
openstack overcloud deploy  \
 --control-scale 3 --compute-scale 1 --ceph-storage-scale 2 \
 --libvirt-type qemu \
 --ntp-server pool.ntp.org  \
 --templates  /usr/share/openstack-tripleo-heat-templates \
 -e  /usr/share/openstack-tripleo-heat-templates/environments/puppet-pacemaker.yaml \
 -e  /usr/share/openstack-tripleo-heat-templates/environments/storage-environment.yaml \
 -e  /usr/share/openstack-tripleo-heat-templates/environments/network-isolation.yaml \
 -e  /usr/share/openstack-tripleo-heat-templates/environments/net-single-nic-with-vlans.yaml \
 -e  $HOME/network_env.yaml

**************************
Deployment completed
**************************

[stack@undercloud ~]$ nova list
+--------------------------------------+-------------------------+--------+------------+-------------+------------------------+
| ID                                   | Name                    | Status | Task State | Power State | Networks               |
+--------------------------------------+-------------------------+--------+------------+-------------+------------------------+
| 028d32a4-6b23-4ed6-9278-cab365378a0e | overcloud-cephstorage-0 | ACTIVE | -          | Running     | ctlplane=192.168.24.14 |
| 4be9eb02-ce0c-475b-aa44-9560781c2c91 | overcloud-cephstorage-1 | ACTIVE | -          | Running     | ctlplane=192.168.24.15 |
| 7b7dcff4-4bb1-4769-85b5-7e4a69a0cd6b | overcloud-controller-0  | ACTIVE | -          | Running     | ctlplane=192.168.24.18 |
| 0a837944-c10e-44c2-a382-04bfcf16b48d | overcloud-controller-1  | ACTIVE | -          | Running     | ctlplane=192.168.24.17 |
| 9a17daf1-ec7f-4220-ba9a-40121a21c997 | overcloud-controller-2  | ACTIVE | -          | Running     | ctlplane=192.168.24.19 |
| 17ebe9c9-2241-428c-88c1-56beba838662 | overcloud-novacompute-0 | ACTIVE | -          | Running     | ctlplane=192.168.24.16 |
+--------------------------------------+-------------------------+--------+------------+-------------+------------------------+

[root@overcloud-controller-1 ~]# ceph status
    cluster a24eec1a-a1bf-11e6-bdb7-00d38065a6b2
     health HEALTH_WARN
            clock skew detected on mon.overcloud-controller-1, mon.overcloud-controller-0
            Monitor clock skew detected
     monmap e1: 3 mons at {overcloud-controller-0=172.16.1.9:6789/0,overcloud-controller-1=172.16.1.8:6789/0,overcloud-controller-2=172.16.1.7:6789/0}
            election epoch 6, quorum 0,1,2 overcloud-controller-2,overcloud-controller-1,overcloud-controller-0
     osdmap e13: 2 osds: 2 up, 2 in
      pgmap v20: 192 pgs, 5 pools, 0 bytes data, 0 objects
            17242 MB used, 85133 MB / 102375 MB avail
                 192 active+clean

[root@overcloud-controller-1 ~]# ceph health detail --format=json-pretty

{
    "health": {
        "health_services": [
            {
                "mons": [
                    {
                        "name": "overcloud-controller-2",
                        "kb_total": 52416312,
                        "kb_used": 8376616,
                        "kb_avail": 44039696,
                        "avail_percent": 84,
                        "last_updated": "2016-11-03 13:16:01.998578",
                        "store_stats": {
                            "bytes_total": 4195635,
                            "bytes_sst": 949,
                            "bytes_log": 4128768,
                            "bytes_misc": 65918,
                            "last_updated": "0.000000"
                        },
                        "health": "HEALTH_OK"
                    },
                    {
                        "name": "overcloud-controller-1",
                        "kb_total": 52416312,
                        "kb_used": 8377052,
                        "kb_avail": 44039260,
                        "avail_percent": 84,
                        "last_updated": "2016-11-03 13:15:57.391923",
                        "store_stats": {
                            "bytes_total": 6292787,
                            "bytes_sst": 949,
                            "bytes_log": 6225920,
                            "bytes_misc": 65918,
                            "last_updated": "0.000000"
                        },
                        "health": "HEALTH_OK"
                    },
                    {
                        "name": "overcloud-controller-0",
                        "kb_total": 52416312,
                        "kb_used": 8376728,
                        "kb_avail": 44039584,
                        "avail_percent": 84,
                        "last_updated": "2016-11-03 13:16:00.579998",
                        "store_stats": {
                            "bytes_total": 6292787,
                            "bytes_sst": 949,
                            "bytes_log": 6225920,
                            "bytes_misc": 65918,
                            "last_updated": "0.000000"
                        },
                        "health": "HEALTH_OK"
                    }
                ]
            }
        ]
    },
    "timechecks": {
        "epoch": 6,
        "round": 14,
        "round_status": "finished",
        "mons": [
            {
                "name": "overcloud-controller-2",
                "skew": 0.000000,
                "latency": 0.000000,
                "health": "HEALTH_OK"
            },
            {
                "name": "overcloud-controller-1",
                "skew": 0.314601,
                "latency": 0.004384,
                "health": "HEALTH_WARN",
                "details": "clock skew 0.314601s > max 0.05s"
            },
            {
                "name": "overcloud-controller-0",
                "skew": 0.974456,
                "latency": 0.004401,
                "health": "HEALTH_WARN",
                "details": "clock skew 0.974456s > max 0.05s"
            }
        ]
    },
    "summary": [
        {
            "severity": "HEALTH_WARN",
            "summary": "Monitor clock skew detected "
        }
    ],
    "overall_status": "HEALTH_WARN",
    "detail": [
        "mon.overcloud-controller-1 addr 172.16.1.8:6789\/0 clock skew 0.314601s > max 0.05s (latency 0.00438388s)",
        "mon.overcloud-controller-0 addr 172.16.1.9:6789\/0 clock skew 0.974456s > max 0.05s (latency 0.00440124s)"
    ]
}

[root@overcloud-controller-0 ~]# pcs status
Cluster name: tripleo_cluster
Last updated: Thu Nov  3 15:46:26 2016        Last change: Thu Nov  3 12:58:12 2016 by root via cibadmin on overcloud-controller-1
Stack: corosync
Current DC: overcloud-controller-2 (version 1.1.13-10.el7_2.4-44eb2dd) - partition with quorum
3 nodes and 127 resources configured

Online: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

Full list of resources:

 ip-172.16.2.5    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-0
 ip-172.16.3.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-1
 Clone Set: haproxy-clone [haproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Master/Slave Set: galera-master [galera]
     Masters: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: memcached-clone [memcached]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 ip-10.0.0.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-2
 ip-172.16.2.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-0
 ip-172.16.1.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-1
 Clone Set: rabbitmq-clone [rabbitmq]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-core-clone [openstack-core]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Master/Slave Set: redis-master [redis]
     Masters: [ overcloud-controller-0 ]
     Slaves: [ overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: mongod-clone [mongod]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 ip-192.168.24.13    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-2
 Clone Set: openstack-aodh-evaluator-clone [openstack-aodh-evaluator]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-scheduler-clone [openstack-nova-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-l3-agent-clone [neutron-l3-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-netns-cleanup-clone [neutron-netns-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-ovs-cleanup-clone [neutron-ovs-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 openstack-cinder-volume    (systemd:openstack-cinder-volume):    Started overcloud-controller-0
 Clone Set: openstack-heat-engine-clone [openstack-heat-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-api-clone [openstack-ceilometer-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-listener-clone [openstack-aodh-listener]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-metadata-agent-clone [neutron-metadata-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-metricd-clone [openstack-gnocchi-metricd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-notifier-clone [openstack-aodh-notifier]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-clone [openstack-heat-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-collector-clone [openstack-ceilometer-collector]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-api-clone [openstack-glance-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-scheduler-clone [openstack-cinder-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-api-clone [openstack-nova-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-consoleauth-clone [openstack-nova-consoleauth]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-api-clone [openstack-sahara-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cloudwatch-clone [openstack-heat-api-cloudwatch]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-engine-clone [openstack-sahara-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-registry-clone [openstack-glance-registry]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-statsd-clone [openstack-gnocchi-statsd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-notification-clone [openstack-ceilometer-notification]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-api-clone [openstack-cinder-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-dhcp-agent-clone [neutron-dhcp-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-openvswitch-agent-clone [neutron-openvswitch-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-novncproxy-clone [openstack-nova-novncproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: delay-clone [delay]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-server-clone [neutron-server]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-central-clone [openstack-ceilometer-central]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: httpd-clone [httpd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cfn-clone [openstack-heat-api-cfn]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-conductor-clone [openstack-nova-conductor]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

PCSD Status:
  overcloud-controller-0: Online
  overcloud-controller-1: Online
  overcloud-controller-2: Online

Daemon Status:
  corosync: active/enabled
  pacemaker: active/enabled
  pcsd: active/enabled

******************************************************************************************
DNS resolution appears to be lost after conversion to rout-able "ctlplane" on HA Controllers,thus HEALTH_WARNING bellow shows up, corresponding qcow2 images scp'ed from undercloud to controller_0
******************************************************************************************

[root@overcloud-controller-0 ~]# ceph status
    cluster a24eec1a-a1bf-11e6-bdb7-00d38065a6b2
     health HEALTH_WARN
            clock skew detected on mon.overcloud-controller-1, mon.overcloud-controller-0
            Monitor clock skew detected
     monmap e1: 3 mons at {overcloud-controller-0=172.16.1.9:6789/0,overcloud-controller-1=172.16.1.8:6789/0,overcloud-controller-2=172.16.1.7:6789/0}
            election epoch 6, quorum 0,1,2 overcloud-controller-2,overcloud-controller-1,overcloud-controller-0
     osdmap e15: 2 osds: 2 up, 2 in
      pgmap v994: 192 pgs, 5 pools, 7106 MB data, 1671 objects
            31432 MB used, 70943 MB / 102375 MB avail
                 192 active+clean
  client io 2255 kB/s rd, 3917 kB/s wr, 142 op/s

[root@overcloud-controller-0 ~]# ceph osd df tree
ID WEIGHT  REWEIGHT SIZE    USE    AVAIL  %USE  VAR  TYPE NAME
-1 0.09998        - 102375M 31444M 70931M 30.71 1.00 root default
-2 0.04999        -  51187M 15723M 35464M 30.72 1.00     host overcloud-cephstorage-1
 0 0.04999  1.00000  51187M 15723M 35464M 30.72 1.00         osd.0
-3 0.04999        -  51187M 15721M 35466M 30.71 1.00     host overcloud-cephstorage-0
 1 0.04999  1.00000  51187M 15721M 35466M 30.71 1.00         osd.1
              TOTAL 102375M 31444M 70931M 30.71
MIN/MAX VAR: 1.00/1.00  STDDEV: 0.00


[root@overcloud-controller-0 ~]# ceph osd df plain

ID WEIGHT  REWEIGHT SIZE    USE    AVAIL  %USE  VAR
 0 0.04999  1.00000  51187M 15723M 35464M 30.72 1.00
 1 0.04999  1.00000  51187M 15721M 35466M 30.71 1.00
              TOTAL 102375M 31444M 70931M 30.71
MIN/MAX VAR: 1.00/1.00  STDDEV: 0.00


[root@overcloud-controller-0 ~]# glance image-list
+--------------------------------------+---------------+
| ID                                   | Name          |
+--------------------------------------+---------------+
| 6c4ff4bc-0b9e-45ee-976c-569a2ffc5421 | CentOS72Cloud |
| 0b6ef368-e91e-4f6f-9e48-4e3ff737faf4 | VF24Cloud     |
+--------------------------------------+---------------+

[root@overcloud-controller-0 ~]# rbd -p images ls
0b6ef368-e91e-4f6f-9e48-4e3ff737faf4
6c4ff4bc-0b9e-45ee-976c-569a2ffc5421

[root@overcloud-controller-0 ~]# cinder list
+--------------------------------------+--------+----------------+------+-------------+----------+--------------------------------------+
|                  ID                  | Status |      Name      | Size | Volume Type | Bootable |             Attached to              |
+--------------------------------------+--------+----------------+------+-------------+----------+--------------------------------------+
| 87367f39-616c-492d-808a-06627fe2dc36 | in-use |   vf24volume   |  10  |      -      |   true   | 20105a2d-1c21-4162-b2cf-1701497690f0 |
| cec9b469-6085-428d-95fc-36fec076580a | in-use | centos72volume |  12  |      -      |   true   | 9ff8b5a9-7485-4b59-9d30-d1259ad91f95 |
+--------------------------------------+--------+----------------+------+-------------+----------+--------------------------------------+

[root@overcloud-controller-0 ~]# rbd -p volumes ls
volume-87367f39-616c-492d-808a-06627fe2dc36
volume-cec9b469-6085-428d-95fc-36fec076580a







No comments:

Post a Comment
