Wednesday, July 27, 2016

TripleO QuickStart vs official Mitaka TripleO HA install via instack-virt-setup

   A final target of this post is to compare undercloud configuration been built by QuickStart and undercloud configuration been built per official documentation
for Mitaka stable , please see Attempt of official Mitaka TripleO HA install via instack-virt-setup
  Final version of instructions set may bee seen here :-
Stable Mitaka HA instack-virt-setup on CentOS 7.2 VIRTHOST

========================
TripleO QuickStart case
========================

First of all right before running `openstack overcloud deploy --templates .... `
Run on undercloud VM following commands :-

[stack@undercloud ~]$ sudo ovs-vsctl show
b8b5ecbc-dc8d-43b8-8f03-09896d1b08b3
    Bridge br-int
        fail_mode: secure
        Port int-br-ctlplane
            Interface int-br-ctlplane
                type: patch
                options: {peer=phy-br-ctlplane}
        Port br-int
            Interface br-int
                type: internal
        Port "tapd7a65b7a-48"
            tag: 1
            Interface "tapd7a65b7a-48"
                type: internal
    Bridge br-ctlplane
        Port "vlan10"
            tag: 10
            Interface "vlan10"
                type: internal
        Port br-ctlplane
            Interface br-ctlplane
                type: internal
        Port "eth1"
            Interface "eth1"
        Port phy-br-ctlplane
            Interface phy-br-ctlplane
                type: patch
                options: {peer=int-br-ctlplane}
    ovs_version: "2.5.0"

=============================

[root@undercloud ~]# ifconfig
br-ctlplane: flags=4163  mtu 1500
        inet 192.0.2.1  netmask 255.255.255.0  broadcast 192.0.2.255
        inet6 fe80::28e:5aff:fe16:9ba1  prefixlen 64  scopeid 0x20
        ether 00:8e:5a:16:9b:a1  txqueuelen 0  (Ethernet)
        RX packets 3383615  bytes 264121585 (251.8 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 4873995  bytes 23750747704 (22.1 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth0: flags=4163  mtu 1500
        inet 192.168.23.10  netmask 255.255.255.0  broadcast 192.168.23.255
        inet6 fe80::28e:5aff:fe16:9b9f  prefixlen 64  scopeid 0x20
        ether 00:8e:5a:16:9b:9f  txqueuelen 1000  (Ethernet)
        RX packets 48092  bytes 42203536 (40.2 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 35731  bytes 4188571 (3.9 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1: flags=4163  mtu 1500
        inet6 fe80::28e:5aff:fe16:9ba1  prefixlen 64  scopeid 0x20
        ether 00:8e:5a:16:9b:a1  txqueuelen 1000  (Ethernet)
        RX packets 3385562  bytes 264368815 (252.1 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 4876692  bytes 23773014677 (22.1 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 3065638  bytes 25610179577 (23.8 GiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 3065638  bytes 25610179577 (23.8 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

virbr0: flags=4099  mtu 1500
        inet 192.168.122.1  netmask 255.255.255.0  broadcast 192.168.122.255
        ether 52:54:00:eb:ef:39  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

vlan10: flags=4163  mtu 1500
        inet 10.0.0.1  netmask 255.255.255.0  broadcast 10.0.0.255
        inet6 fe80::5ce2:8eff:fed9:2f89  prefixlen 64  scopeid 0x20
        ether 5e:e2:8e:d9:2f:89  txqueuelen 0  (Ethernet)
        RX packets 1154  bytes 176564 (172.4 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1759  bytes 22168381 (21.1 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

===============================================
Analyze code undercloud-post-install.sh following bellow
===============================================
[stack@undercloud ~]$ cat  undercloud-post-install.sh
#!/bin/bash

# Prepare the undercloud for deploy

set -eux

# Source in undercloud credentials.
source /home/stack/stackrc
######################
# Set of standard commands
######################

# Upload images to glance.
openstack overcloud image upload \

openstack baremetal import --json instackenv.json
openstack baremetal configure boot

# Perform introspection if requested.

. . . . . . . .

################################################
# Here follows critical VM network configuration portion
################################################

# enable NAT for "external" network
RULE="-s 10.0.0.1/24 ! -d 10.0.0.1/24 -j MASQUERADE"

if ! sudo iptables -t nat -C BOOTSTACK_MASQ $RULE; then
    sudo iptables -t nat -A BOOTSTACK_MASQ $RULE
    sudo sh -c 'iptables-save > /etc/sysconfig/iptables'
fi

sudo bash -c 'cat < /etc/sysconfig/network-scripts/ifcfg-vlan10
DEVICE=vlan10
ONBOOT=yes
DEVICETYPE=ovs
TYPE=OVSIntPort
BOOTPROTO=static
IPADDR=10.0.0.1
NETMASK=255.255.255.0
OVS_BRIDGE=br-ctlplane
OVS_OPTIONS="tag=10"
EOF'

sudo ifup ifcfg-vlan10

# clone the t-h-t templates if neede
d

=========================================
So finally up on overcloud-deployment completion :-
=========================================

[root@undercloud ~]# ip netns
qdhcp-74126965-fbac-483d-9d8d-1c2ff43a2bd2
[root@undercloud ~]# ip netns exec qdhcp-74126965-fbac-483d-9d8d-1c2ff43a2bd2 ifconfig
lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

tapd7a65b7a-48: flags=4163  mtu 1500
        inet 192.0.2.5  netmask 255.255.255.0  broadcast 192.0.2.255
        inet6 fe80::f816:3eff:fe9d:1a65  prefixlen 64  scopeid 0x20
        ether fa:16:3e:9d:1a:65  txqueuelen 0  (Ethernet)
        RX packets 1109  bytes 103765 (101.3 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 943  bytes 91866 (89.7 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

[root@undercloud ~]# ip netns exec qdhcp-74126965-fbac-483d-9d8d-1c2ff43a2bd2 route -n
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
0.0.0.0         192.0.2.1       0.0.0.0         UG    0      0        0 tapd7a65b7a-48
192.0.2.0       0.0.0.0         255.255.255.0   U     0      0        0 tapd7a65b7a-48


=======================================================
Get back to `ovs-vsctl show` on undercloud generated by QuickStart
=======================================================

Focus on device tapd7a65b7a-48 and vlan10

[stack@undercloud ~]$ sudo ovs-vsctl show
b8b5ecbc-dc8d-43b8-8f03-09896d1b08b3
    Bridge br-int
        fail_mode: secure
        Port int-br-ctlplane
            Interface int-br-ctlplane
                type: patch
                options: {peer=phy-br-ctlplane}  <=== veth pair connecting br-int
        Port br-int                                                               and br-ctlplane
            Interface br-int
                type: internal
        Port "tapd7a65b7a-48"
            tag: 1
            Interface "tapd7a65b7a-48"
                type: internal
    Bridge br-ctlplane
        Port "vlan10"
            tag: 10
            Interface "vlan10"
                type: internal
        Port br-ctlplane
            Interface br-ctlplane
                type: internal
        Port "eth1"
            Interface "eth1"
        Port phy-br-ctlplane
            Interface phy-br-ctlplane
                type: patch
                options: {peer=int-br-ctlplane}  <=== veth pair connecting
    ovs_version: "2.5.0"                                          connecting br-int and
                                                                             br-ctlplane

==================================================================
==================================================================

[stack@ServerCentOS72 ~]$ virsh list --all
 Id    Name                           State
----------------------------------------------------
 2     instack                        running
 -     baremetalbrbm_0                shut off
 -     baremetalbrbm_1                shut off
 -     baremetalbrbm_2                shut off
 -     baremetalbrbm_3                shut off

[stack@ServerCentOS72 ~]$ ssh root@192.168.122.193
Last login: Mon Jul 25 13:59:52 2016 from 192.168.122.1
[root@instack ~]# su - stack
Last login: Mon Jul 25 13:59:54 UTC 2016 on pts/5
[stack@instack ~]$ . stackrc
[stack@instack ~]$ sudo ovs-vsctl show
bc1c13cd-3651-4f79-87df-bdaf4f5fec01
    Bridge br-ctlplane
        Port br-ctlplane
            Interface br-ctlplane
                type: internal
        Port phy-br-ctlplane
            Interface phy-br-ctlplane
                type: patch
                options: {peer=int-br-ctlplane}
        Port "eth1"
            Interface "eth1"
        Port "vlan10"
            tag: 10
            Interface "vlan10"
                error: "could not open network device vlan10 (No such device)"

    Bridge br-int
        fail_mode: secure
        Port "tap41e6fddf-31"
            tag: 1
            Interface "tap41e6fddf-31"
                type: internal
        Port int-br-ctlplane
            Interface int-br-ctlplane
                type: patch
                options: {peer=phy-br-ctlplane}
        Port br-int
            Interface br-int
                type: internal
    ovs_version: "2.5.0"

[stack@instack ~]$ ifconfig
br-ctlplane: flags=4163  mtu 1500
        inet 192.0.2.1  netmask 255.255.255.0  broadcast 192.0.2.255
        inet6 fe80::297:fff:fe5c:c66c  prefixlen 64  scopeid 0x20
        ether 00:97:0f:5c:c6:6c  txqueuelen 0  (Ethernet)
        RX packets 13  bytes 1038 (1.0 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 12  bytes 816 (816.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth0: flags=4163  mtu 1500
        inet 192.168.122.193  netmask 255.255.255.0  broadcast 192.168.122.255
        inet6 fe80::5054:ff:fe6f:906a  prefixlen 64  scopeid 0x20
        ether 52:54:00:6f:90:6a  txqueuelen 1000  (Ethernet)
        RX packets 1674  bytes 213273 (208.2 KiB)
        RX errors 0  dropped 9  overruns 0  frame 0
        TX packets 1078  bytes 163033 (159.2 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1: flags=4163  mtu 1500
        inet6 fe80::297:fff:fe5c:c66c  prefixlen 64  scopeid 0x20
        ether 00:97:0f:5c:c6:6c  txqueuelen 1000  (Ethernet)
        RX packets 8  bytes 648 (648.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 14  bytes 1108 (1.0 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 31888  bytes 10276736 (9.8 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 31888  bytes 10276736 (9.8 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

=======================================================
Thus any attempt to activate "Network Isolation"  having External Network
  running within
=======================================================

 openstack overcloud deploy --templates --libvirt-type qemu \
--control-scale 3 \
--compute-scale 1 \
-e /usr/share/openstack-tripleo-heat-templates/environments/puppet-pacemaker.yaml \
--ntp-server pool.ntp.org

after committing all instructions from http://docs.openstack.org/developer/tripleo-docs/basic_deployment/basic_deployment_cli.html
is supposed to fail. Instack VM is missing device vlan10 supposed to become external interface attached as OVS port to br-ctlplane. What I believe was done in http://mariosandreou.com/tripleo/2016/06/17/deploy-tripleo-stable-mitaka.html  without explicitly advertising.

=================================================================
Get back to post mentioned in the header , we want Mitaka Tripleo deployment
to run on instack VM with "Network Isolation" setting up External network,
Network serving VXLAN tunnels . In regards of Ceph Nodes overcloud deployment "Network Isolation"  is obviously extremely important.
So, vlan10 device creation should be done with no doubts.
=================================================================

sudo bash -c 'cat <  /etc/sysconfig/network-scripts/ifcfg-vlan10
DEVICE=vlan10
ONBOOT=yes
DEVICETYPE=ovs
TYPE=OVSIntPort
BOOTPROTO=static
IPADDR=10.0.0.1
NETMASK=255.255.255.0
OVS_BRIDGE=br-ctlplane
OVS_OPTIONS="tag=10"
EOF'

sudo ifup ifcfg-vlan10

sudo iptables -A BOOTSTACK_MASQ -s 10.0.0.0/24 ! -d 10.0.0.0/24 -j MASQUERADE -t nat

=============================
Make sure updates are done
=============================

[boris@ServerCentOS72 ~]$ sudo su -
[sudo] password for boris:
Last login: Tue Jul 26 03:58:20 MSK 2016 on pts/0
[root@ServerCentOS72 ~]# su - stack
Last login: Tue Jul 26 03:58:45 MSK 2016 on pts/0
[stack@ServerCentOS72 ~]$ ssh root@192.168.122.193
Last login: Tue Jul 26 01:01:49 2016
[root@instack ~]# su - stack
Last login: Tue Jul 26 01:01:34 UTC 2016 on pts/0
[stack@instack ~]$ sudo ovs-vsctl show
bc1c13cd-3651-4f79-87df-bdaf4f5fec01
    Bridge br-ctlplane
        Port "eth1"
            Interface "eth1"
        Port br-ctlplane
            Interface br-ctlplane
                type: internal
        Port phy-br-ctlplane
            Interface phy-br-ctlplane
                type: patch
                options: {peer=int-br-ctlplane}
        Port "vlan10"
            tag: 10
            Interface "vlan10"
                type: internal
    Bridge br-int
        fail_mode: secure
        Port "tap41e6fddf-31"
            tag: 1
            Interface "tap41e6fddf-31"
                type: internal
        Port int-br-ctlplane
            Interface int-br-ctlplane
                type: patch
                options: {peer=phy-br-ctlplane}
        Port br-int
            Interface br-int
                type: internal
    ovs_version: "2.5.0"
[stack@instack ~]$ ifconfig
br-ctlplane: flags=4163  mtu 1500
        inet 192.0.2.1  netmask 255.255.255.0  broadcast 192.0.2.255
        inet6 fe80::297:fff:fe5c:c66c  prefixlen 64  scopeid 0x20
        ether 00:97:0f:5c:c6:6c  txqueuelen 0  (Ethernet)
        RX packets 2751712  bytes 205714576 (196.1 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 2711617  bytes 12789727774 (11.9 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth0: flags=4163  mtu 1500
        inet 192.168.122.193  netmask 255.255.255.0  broadcast 192.168.122.255
        inet6 fe80::5054:ff:fe6f:906a  prefixlen 64  scopeid 0x20
        ether 52:54:00:6f:90:6a  txqueuelen 1000  (Ethernet)
        RX packets 4767  bytes 590862 (577.0 KiB)
        RX errors 0  dropped 9  overruns 0  frame 0
        TX packets 3138  bytes 488880 (477.4 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1: flags=4163  mtu 1500
        inet6 fe80::297:fff:fe5c:c66c  prefixlen 64  scopeid 0x20
        ether 00:97:0f:5c:c6:6c  txqueuelen 1000  (Ethernet)
        RX packets 2751684  bytes 205708317 (196.1 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 2711674  bytes 12789742191 (11.9 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 319388  bytes 1493930109 (1.3 GiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 319388  bytes 1493930109 (1.3 GiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

vlan10: flags=4163  mtu 1500
        inet 10.0.0.1  netmask 255.255.255.0  broadcast 10.0.0.255
        inet6 fe80::1478:deff:fe20:7b86  prefixlen 64  scopeid 0x20
        ether 16:78:de:20:7b:86  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 12  bytes 816 (816.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

==================================================
Proceed as follows.   Create file network-environment template :-
==================================================
[stack@instack ~]$ cat network_env.yaml
{
    "parameter_defaults": {
        "ControlPlaneDefaultRoute": "192.0.2.1",
        "ControlPlaneSubnetCidr": "24",
        "DnsServers": [
            "192.168.23.1"
        ],
        "EC2MetadataIp": "192.0.2.1",
        "ExternalAllocationPools": [
            {
                "end": "10.0.0.250",
                "start": "10.0.0.4"
            }
        ],
        "ExternalNetCidr": "10.0.0.1/24",
        "NeutronExternalNetworkBridge": ""
    }
}

=====================
Then run :-
=====================
[stack@instack ~]$ source stackrc

[stack@instack ~]$ openstack overcloud deploy --templates --control-scale 3 \
  --compute-scale 1 \
  --libvirt-type qemu \
  --ntp-server pool.ntp.org  \
  -e  /usr/share/openstack-tripleo-heat-templates/environments/puppet-pacemaker.yaml \
  -e  /usr/share/openstack-tripleo-heat-templates/environments/network-isolation.yaml \
  -e  /usr/share/openstack-tripleo-heat-templates/environments/net-single-nic-with-vlans.yaml \
  -e  $HOME/network_env.yaml
. . . .

Stack overcloud CREATE_COMPLETE
/home/stack/.ssh/known_hosts updated.
Original contents retained as /home/stack/.ssh/known_hosts.old
Skipping "horizon" postconfig because it wasn't found in the endpoint map output
PKI initialization in init-keystone is deprecated and will be removed.
Warning: Permanently added '192.0.2.16' (ECDSA) to the list of known hosts.
The following cert files already exist, use --rebuild to remove the existing files before regenerating:
/etc/keystone/ssl/certs/ca.pem already exists
/etc/keystone/ssl/private/signing_key.pem already exists
/etc/keystone/ssl/certs/signing_cert.pem already exists
Connection to 192.0.2.16 closed.
Overcloud Endpoint: http://10.0.0.4:5000/v2.0
Overcloud Deployed

[stack@instack ~]$ nova list
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+
| ID                                   | Name                    | Status | Task State | Power State | Networks            |
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+
| 068dcf61-1c07-49d3-97f9-66e0ff1896e4 | overcloud-controller-0  | ACTIVE | -          | Running     | ctlplane=192.0.2.19 |
| 1083bc50-4e30-4a8d-8a02-d60c35bab0b7 | overcloud-controller-1  | ACTIVE | -          | Running     | ctlplane=192.0.2.18 |
| 3d88de4e-2c25-4a7e-ac05-580d5e4532f5 | overcloud-controller-2  | ACTIVE | -          | Running     | ctlplane=192.0.2.20 |
| f4589428-ba17-44f5-b73c-db38af7963e9 | overcloud-novacompute-0 | ACTIVE | -          | Running     | ctlplane=192.0.2.17 |
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+


[stack@instack ~]$ neutron net-list
+--------------------------------------+--------------+--------------------------------------------+
| id                                   | name         | subnets                                    |
+--------------------------------------+--------------+--------------------------------------------+
| cc29c009-f2c8-457c-a92c-021acf650b78 | tenant       | 3afaf44d-19b5-46ac-8534-fe1520a14a1c       |
|                                      |              | 172.16.0.0/24                              |
| e8e8d778-1992-4ee2-9b4e-ac349e8d7985 | external     | 8ad5eeef-6860-4781-89e6-5132cf633013       |
|                                      |              | 10.0.0.0/24                                |
| 00bbd0fb-94b0-406a-b5b1-aa60b5526898 | internal_api | 1b84e01e-deb9-458c-990a-94d92f69f668       |
|                                      |              | 172.16.2.0/24                              |
| 65d426b0-0b02-4654-b598-1ba368a43d35 | storage      | 849719fb-877c-49f7-a606-959e4720011d       |
|                                      |              | 172.16.1.0/24                              |
| 687769a2-5438-434d-8085-2988e592755b | storage_mgmt | fc36759d-25ee-4cbe-908b-819dad6a222d       |
|                                      |              | 172.16.3.0/24                              |
| 584468f0-d26e-4a47-89a1-bca5847404fb | ctlplane     | 43d05014-098b-4eb5-8582-178404ff0e24       |
|                                      |              | 192.0.2.0/24                               |
+--------------------------------------+--------------+--------------------------------------------+

[stack@instack ~]$ ssh heat-admin@192.0.2.19
The authenticity of host '192.0.2.19 (192.0.2.19)' can't be established.
ECDSA key fingerprint is 61:31:94:19:12:51:a3:df:be:22:f6:0a:e7:dc:a1:d7.
Are you sure you want to continue connecting (yes/no)? yes
Warning: Permanently added '192.0.2.19' (ECDSA) to the list of known hosts.
Last login: Tue Jul 26 02:00:36 2016 from 192.0.2.1
[heat-admin@overcloud-controller-0 ~]$ sudo su -
[root@overcloud-controller-0 ~]# pcs status
Cluster name: tripleo_cluster
Last updated: Tue Jul 26 02:03:03 2016        Last change: Tue Jul 26 01:58:37 2016 by root via cibadmin on overcloud-controller-0
Stack: corosync
Current DC: overcloud-controller-2 (version 1.1.13-10.el7_2.2-44eb2dd) - partition with quorum
3 nodes and 127 resources configured

Online: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

Full list of resources:

 ip-192.0.2.16    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-0
 ip-172.16.2.5    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-1
 ip-172.16.3.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-2
 Clone Set: haproxy-clone [haproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Master/Slave Set: galera-master [galera]
     Masters: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: memcached-clone [memcached]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 ip-10.0.0.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-0
 ip-172.16.2.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-1
 ip-172.16.1.4    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-2
 Clone Set: rabbitmq-clone [rabbitmq]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-core-clone [openstack-core]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Master/Slave Set: redis-master [redis]
     Masters: [ overcloud-controller-0 ]
     Slaves: [ overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: mongod-clone [mongod]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-evaluator-clone [openstack-aodh-evaluator]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-scheduler-clone [openstack-nova-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-l3-agent-clone [neutron-l3-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-netns-cleanup-clone [neutron-netns-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-ovs-cleanup-clone [neutron-ovs-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 openstack-cinder-volume    (systemd:openstack-cinder-volume):    Started overcloud-controller-0
 Clone Set: openstack-heat-engine-clone [openstack-heat-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-api-clone [openstack-ceilometer-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-listener-clone [openstack-aodh-listener]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-metadata-agent-clone [neutron-metadata-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-metricd-clone [openstack-gnocchi-metricd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-notifier-clone [openstack-aodh-notifier]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-clone [openstack-heat-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-collector-clone [openstack-ceilometer-collector]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-api-clone [openstack-glance-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-scheduler-clone [openstack-cinder-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-api-clone [openstack-nova-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-consoleauth-clone [openstack-nova-consoleauth]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-api-clone [openstack-sahara-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cloudwatch-clone [openstack-heat-api-cloudwatch]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-engine-clone [openstack-sahara-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-registry-clone [openstack-glance-registry]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-statsd-clone [openstack-gnocchi-statsd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-notification-clone [openstack-ceilometer-notification]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-api-clone [openstack-cinder-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-dhcp-agent-clone [neutron-dhcp-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-openvswitch-agent-clone [neutron-openvswitch-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-novncproxy-clone [openstack-nova-novncproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: delay-clone [delay]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-server-clone [neutron-server]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-central-clone [openstack-ceilometer-central]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: httpd-clone [httpd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cfn-clone [openstack-heat-api-cfn]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-conductor-clone [openstack-nova-conductor]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

PCSD Status:
  overcloud-controller-0: Online
  overcloud-controller-1: Online
  overcloud-controller-2: Online

Daemon Status:
  corosync: active/enabled
  pacemaker: active/enabled
  pcsd: active/enabled

===============================================
Verification Galera in sync &&  rabbitmqctl cluster_status
===============================================






Saturday, June 4, 2016

Triple0 QuickStart HA Setup on Intel Core i7-4790 Desktop

This posting follows up Deploying OpenStack on just one hosted server   but is focused on utilizing i7 4790/4770  CPUs  with inexpensive boards like ASUS Z97-P having 32 GB RAM.  As remote workstation C2D E8400 with 8 GB RAM has been used . OS installed on both PCs was CentOS 7.2 (Release 1604). Mentioned  environment allows in about couple of hours to obtain stable working configuration based on ha.yml template :-

######################
# Template code
######################
# Deploy an HA openstack environment.
#
# This will require (6144 * 4) == approx. 24GB for the overcloud
# nodes, plus another 8GB for the undercloud, for a total of around
# 32GB.
control_memory: 6144
compute_memory: 6144

undercloud_memory: 8192

# Giving the undercloud additional CPUs can greatly improve heat's
# performance (and result in a shorter deploy time).
undercloud_vcpu: 4

# Create three controller nodes and one compute node.
overcloud_nodes:
  - name: control_0
    flavor: control
  - name: control_1
    flavor: control
  - name: control_2
    flavor: control

  - name: compute_0
    flavor: compute
  - name: compute_1
    flavor: compute

# We don't need introspection in a virtual environment (because we are
# creating all the "hardware" we really know the necessary
# information).
introspect: false

# Tell tripleo about our environment.
network_isolation: true
extra_args: >-
  --control-scale 3 --compute-scale 2 --neutron-network-type vxlan
  --neutron-tunnel-types vxlan
  -e /usr/share/openstack-tripleo-heat-templates/environments/puppet-pacemaker.yaml
  --ntp-server pool.ntp.org
deploy_timeout: 75
tempest: false
pingtest: true


**********************************************************************************
Fist fix bugs mentioned in link above on the Server's  Desktop
and run  `yum groupinstall "Virtualization Host"`
**********************************************************************************

Then start on workstation :-

$ git clone https://github.com/openstack/tripleo-quickstart
$ cd tripleo-quickstart
$ sudo bash quickstart.sh --install-deps
$ sudo yum -y  install redhat-rpm-config


$export VIRTHOST=192.168.1.75 #put your own IP here
$ ssh-keygen
$ssh-copy-id root@$VIRTHOST
$ssh root@$VIRTHOST uname -a # no root login prompt

Then run under tripleo-quickstart

$ bash quickstart.sh --config ./config/general_config/ha.yml  $VIRTHOST

If everything went well you will be brought back to command prompt
and see following output

##################################
Virtual Environment Setup Complete
##################################


Access the undercloud by:

 ssh -F /home/boris/.quickstart/ssh.config.ansible undercloud

There are scripts in the home directory to continue the deploy:

 undercloud-install.sh will run the undercloud install
 undercloud-post-install.sh will perform all pre-deploy steps
 overcloud-deploy.sh will deploy the overcloud
 overcloud-deploy-post.sh will do any post-deploy configuration
 overcloud-validate.sh will run post-deploy validation

During overcloud deployment open remote ssh session to server and run top
You will see that memory allocation matches your  ha.yml
When done : su - stack on Server

[root@ServerCentOS72 ~]# su - stack
Last login: Sun Jun  5 09:08:16 MSK 2016 from 192.168.1.54 on pts/0
[stack@ServerCentOS72 ~]$ virsh list
 Id    Name                           State
----------------------------------------------------
 2     undercloud                     running
 8     control_1                      running
 9     compute_0                      running
 10    compute_1                      running
 11    control_0                      running
 12    control_2                      running


[stack@ServerCentOS72 ~]$ virsh dumpxml undercloud | grep vcpu
 <vcpu placement='static'>4</vcpu>
[stack@ServerCentOS72 ~]$ virsh dumpxml undercloud | grep memory
  <memory unit='KiB'>8388608</memory>
[stack@ServerCentOS72 ~]$ virsh dumpxml control_0  | grep memory
  <memory unit='KiB'>6291456</memory>
[stack@ServerCentOS72 ~]$ virsh dumpxml control_0  | grep cpu
  <vcpu placement='static'>1</vcpu>
  <cpu mode='host-passthrough'/>
[stack@ServerCentOS72 ~]$ virsh dumpxml compute_0  | grep cpu
  <vcpu placement='static'>1</vcpu>
  <cpu mode='host-passthrough'/>
[stack@ServerCentOS72 ~]$ virsh dumpxml compute_0  | grep memory
  <memory unit='KiB'>6291456</memory>

***************************************
Up on completion of last script run :-
***************************************
[stack@undercloud ~]$ . stackrc
[stack@undercloud ~]$ heat stack-list
+--------------------------------------+------------+-----------------+---------------------+--------------+
| id                                   | stack_name | stack_status    | creation_time       | updated_time |
+--------------------------------------+------------+-----------------+---------------------+--------------+
| 4474e9c7-74a0-4ba6-9cb4-889127a31c1f | overcloud  | CREATE_COMPLETE | 2016-06-05T06:27:44 | None         |
+--------------------------------------+------------+-----------------+---------------------+--------------+

[stack@undercloud ~]$ nova list
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+
| ID                                   | Name                    | Status | Task State | Power State | Networks            |
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+
| b1d93ac8-3e00-4f5c-8d02-73f0853c7297 | overcloud-controller-0  | ACTIVE | -          | Running     | ctlplane=192.0.2.11 |
| 69c560b7-7fcd-442e-8360-3c85f686b19f | overcloud-controller-1  | ACTIVE | -          | Running     | ctlplane=192.0.2.9  |
| ce73a87b-e49d-4b4b-9d45-b4297c39dbaf | overcloud-controller-2  | ACTIVE | -          | Running     | ctlplane=192.0.2.12 |
| 4cb7cb86-9f72-4654-ae83-34bd1e1576e7 | overcloud-novacompute-0 | ACTIVE | -          | Running     | ctlplane=192.0.2.10 |
| 391d13b4-ed9b-45d4-96a4-f97b07d53088 | overcloud-novacompute-1 | ACTIVE | -          | Running     | ctlplane=192.0.2.8  |
+--------------------------------------+-------------------------+--------+------------+-------------+---------------------+


[stack@undercloud ~]$ ssh heat-admin@192.0.2.11
Last login: Sun Jun  5 08:34:21 2016 from gateway
[heat-admin@overcloud-controller-0 ~]$ sudo su -
Last login: Sun Jun  5 08:34:26 UTC 2016 on pts/0

[root@overcloud-controller-0 ~]# . keystonerc_admin
[root@overcloud-controller-0 ~]# neutron net-list
+---------------------------------+---------------------------------+-----------------------------------+
| id                              | name                            | subnets                           |
+---------------------------------+---------------------------------+-----------------------------------+
| 548abd13-dd34-4b8a-             | public                          | 8887421f-                         |
| b3b2-ccebc87ebffa               |                                 | eb7b-4639-b7be-066873038434       |
|                                 |                                 | 192.0.2.0/24                      |
| 7fe9187a-d46c-4e03-9e1f-        | HA network tenant 773c2a0603eb4 | 967d823a-                         |
| ae4ab56ca12f                    | 72eb1ca050a69f8ddfb             | 0fb0-4e80-99b0-977dfcead5b9       |
|                                 |                                 | 169.254.192.0/18                  |
| 2530d88f-5b03-4d8c-beab-        | demo_network                    | 83c1fd7f-3ee6-49f8-bdcb-          |
| ce176394aa8f                    |                                 | 132771a875d5 50.0.0.0/24          |
+---------------------------------+---------------------------------+-----------------------------------+

[root@overcloud-controller-0 ~]# pcs status
Cluster name: tripleo_cluster
Last updated: Sun Jun  5 07:20:59 2016        Last change: Sun Jun  5 07:10:31 2016 by root via cibadmin on overcloud-controller-0
Stack: corosync
Current DC: overcloud-controller-2 (version 1.1.13-10.el7_2.2-44eb2dd) - partition with quorum
3 nodes and 123 resources configured

Online: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

Full list of resources:

 ip-192.0.2.6    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-0
 Clone Set: haproxy-clone [haproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 ip-192.0.2.7    (ocf::heartbeat:IPaddr2):    Started overcloud-controller-1
 Master/Slave Set: galera-master [galera]
     Masters: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: memcached-clone [memcached]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: rabbitmq-clone [rabbitmq]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-core-clone [openstack-core]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Master/Slave Set: redis-master [redis]
     Masters: [ overcloud-controller-1 ]
     Slaves: [ overcloud-controller-0 overcloud-controller-2 ]
 Clone Set: mongod-clone [mongod]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-evaluator-clone [openstack-aodh-evaluator]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-scheduler-clone [openstack-nova-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-l3-agent-clone [neutron-l3-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-netns-cleanup-clone [neutron-netns-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-ovs-cleanup-clone [neutron-ovs-cleanup]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 openstack-cinder-volume    (systemd:openstack-cinder-volume):    Started overcloud-controller-2
 Clone Set: openstack-heat-engine-clone [openstack-heat-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-api-clone [openstack-ceilometer-api]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-listener-clone [openstack-aodh-listener]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-metadata-agent-clone [neutron-metadata-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-metricd-clone [openstack-gnocchi-metricd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-aodh-notifier-clone [openstack-aodh-notifier]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-clone [openstack-heat-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-collector-clone [openstack-ceilometer-collector]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-api-clone [openstack-glance-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-scheduler-clone [openstack-cinder-scheduler]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-api-clone [openstack-nova-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-consoleauth-clone [openstack-nova-consoleauth]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-api-clone [openstack-sahara-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cloudwatch-clone [openstack-heat-api-cloudwatch]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-sahara-engine-clone [openstack-sahara-engine]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-glance-registry-clone [openstack-glance-registry]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-gnocchi-statsd-clone [openstack-gnocchi-statsd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-notification-clone [openstack-ceilometer-notification]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-cinder-api-clone [openstack-cinder-api]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-dhcp-agent-clone [neutron-dhcp-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-openvswitch-agent-clone [neutron-openvswitch-agent]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-novncproxy-clone [openstack-nova-novncproxy]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: delay-clone [delay]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: neutron-server-clone [neutron-server]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-ceilometer-central-clone [openstack-ceilometer-central]
     Stopped: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: httpd-clone [httpd]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-heat-api-cfn-clone [openstack-heat-api-cfn]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]
 Clone Set: openstack-nova-conductor-clone [openstack-nova-conductor]
     Started: [ overcloud-controller-0 overcloud-controller-1 overcloud-controller-2 ]

Failed Actions:

 * openstack-aodh-evaluator_monitor_60000 on overcloud-controller-1 'not running' (7): call=78, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:06:55 2016', queued=0ms, exec=0ms
* openstack-ceilometer-central_start_0 on overcloud-controller-1 'not running' (7): call=316, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:13:25 2016', queued=0ms, exec=2113ms
* openstack-aodh-evaluator_monitor_60000 on overcloud-controller-0 'not running' (7): call=77, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:06:52 2016', queued=0ms, exec=0ms
* openstack-ceilometer-central_start_0 on overcloud-controller-0 'not running' (7): call=268, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:09:40 2016', queued=0ms, exec=2209ms
* openstack-aodh-evaluator_monitor_60000 on overcloud-controller-2 'not running' (7): call=76, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:06:51 2016', queued=0ms, exec=0ms
* openstack-ceilometer-central_start_0 on overcloud-controller-2 'not running' (7): call=312, status=complete, exitreason='none',
    last-rc-change='Sun Jun  5 07:13:30 2016', queued=0ms, exec=2119ms


PCSD Status:
  overcloud-controller-0: Online
  overcloud-controller-1: Online
  overcloud-controller-2: Online

Daemon Status:
  corosync: active/enabled
  pacemaker: active/enabled
  pcsd: active/enabled



  Neutron reports




   System reports






   Running instances



*****************************************************
 Connections to VMs from undercloud
*****************************************************
 [stack@undercloud ~]$ ssh -i oskey060516.pem fedora@192.0.2.151
Last login: Sun Jun  5 09:17:05 2016 from 192.0.2.1
[fedora@vf23dev01 ~]$ uname -a
Linux vf23dev01.localdomain 4.5.5-201.fc23.x86_64 #1 SMP Sat May 21 15:29:49 UTC 2016 x86_64 x86_64 x86_64 GNU/Linux
[fedora@vf23dev01 ~]$ Connection to 192.0.2.151 closed.
[stack@undercloud ~]$ ssh -i oskey060516.pem ubuntu@192.0.2.152
Welcome to Ubuntu 16.04 LTS (GNU/Linux 4.4.0-22-generic x86_64)

 * Documentation:  https://help.ubuntu.com/

  Get cloud support with Ubuntu Advantage Cloud Guest:
    http://www.ubuntu.com/business/services/cloud

14 packages can be updated.
5 updates are security updates.


Last login: Sun Jun  5 08:32:52 2016 from 192.0.2.1
ubuntu@ubuntudevs01:~$ uname -a
Linux ubuntudevs01 4.4.0-22-generic #40-Ubuntu SMP Thu May 12 22:03:46 UTC 2016 x86_64 x86_64 x86_64 GNU/Linux
ubuntu@ubuntudevs01:~$ logout
Connection to 192.0.2.152 closed.



   Hypervisors  on overcloud



   Server's CentOS 7.2 `top` report


Regarding details of ovecloud server's configuration

[root@overcloud-controller-0 network-scripts]# cat ifcfg-br-ex
# This file is autogenerated by os-net-config
DEVICE=br-ex
ONBOOT=yes
HOTPLUG=no
NM_CONTROLLED=no
DEVICETYPE=ovs
TYPE=OVSBridge
OVSBOOTPROTO=dhcp
OVSDHCPINTERFACES="eth0"
OVS_EXTRA="set bridge br-ex other-config:hwaddr=00:83:94:4b:f4:bf"

[root@overcloud-controller-0 network-scripts]# ifconfig
br-ex: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 192.0.2.10  netmask 255.255.255.0  broadcast 192.0.2.255
        inet6 fe80::283:94ff:fe4b:f4bf  prefixlen 64  scopeid 0x20<link>
        ether 00:83:94:4b:f4:bf  txqueuelen 0  (Ethernet)
        RX packets 1524142  bytes 482079467 (459.7 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1479958  bytes 289821172 (276.3 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet6 fe80::283:94ff:fe4b:f4bf  prefixlen 64  scopeid 0x20<link>
        ether 00:83:94:4b:f4:bf  txqueuelen 1000  (Ethernet)
        RX packets 1524492  bytes 482222219 (459.8 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1480362  bytes 289890148 (276.4 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0



  Watch https://www.youtube.com/watch?v=8zFQG5mKwPk&feature=autoshare

Monday, May 23, 2016

Java EE Servers as Nova-Docker Containers && RDO Mitaka External vlan networks

  Nova-Docker driver is installed on Compute node which is supposed to run two Java EE Servers as light weight Nova-Docker Containers (instances) having floating IPs on two different external vlan enabled subnets (10.10.10.0/24; 10.10.50.0/24).  General Setup RDO Mitaka ML2&OVS&VLAN 3 Nodes.  VLAN tenant's segregation for RDO lansdcape was selected to avoid DVR configuration Controller && Compute Cluster.
Details here Setup Docker Hypervisor on Multi Node DVR Cluster RDO Mitaka

  Thus Controller/Network RDO Mitaka Node has to have external networks of VLAN type with predefined vlan tags. Straight forward packstack deployment doesn't  allow to achieve desired network configuration. External network provider of vlan type appears to be required.
   Also I have to notice that Docker Hypervisor running on Compute Node
requires all deployment nodes set SELINUX to PERMISSIVE MODE.

   In particular case, office networks 10.10.10.0/24 is vlan tagged (157), 10.10.50.0/24 is vlan tagged (172) already exists when RDO install is running.

192.169.142.127 Controller/Network
192.169.142.147 Storage Node
192.169.142.137 Compute Node
192.169.142.45   WKS ( 3VNICs eth0 - 192.169.142.45 , eth1.157 - 10.10.10.45, eth2.172 - 10.10.50.45 ), running web browser to connect to Java Servers

First

***********************************************************
Update /etc/neutron/plugins/ml2/ml2_conf.ini
***********************************************************

[root@ip-192-169-142-127 ml2(keystone_demo)]# cat ml2_conf.ini
[ml2]
type_drivers = flat,vlan,vxlan
tenant_network_types = vlan,vxlan
mechanism_drivers =openvswitch
path_mtu = 0
[ml2_type_flat]
[ml2_type_vlan]
network_vlan_ranges =physnet1:100:200,vlan157:157:157,vlan172:172:172,physnet4
[ml2_type_gre]
[ml2_type_vxlan]
vni_ranges =10:100
vxlan_group =224.0.0.1
[ml2_type_geneve]
[securitygroup]
enable_security_group = True

**************
Then
**************

# openstack-service restart neutron

***************************************************
Invoke external network provider
***************************************************

[root@ip-192-169-142-127 ~(keystone_admin]#neutron net-create vlan157 --shared --provider:network_type vlan --provider:segmentation_id 157 --provider:physical_network vlan157 --router:external

[root@ip-192-169-142-127 ~(keystone_admin]# neutron subnet-create --name sub-vlan157 --gateway 10.10.10.1  --allocation-pool start=10.10.10.100,end=10.10.10.200 vlan157 10.10.10.0/24

***********************************************
Create second external vlan network
***********************************************

[root@ip-192-169-142-127 ~(keystone_admin]# neutron net-create vlan172 --shared --provider:network_type vlan --provider:segmentation_id 172 --provider:physical_network vlan172  --router:external

[root@ip-192-169-142-127 ~(keystone_admin]# neutron subnet-create --name sub-vlan172 --gateway 10.10.50.1 --allocation-pool start=10.10.50.100,end=10.10.50.200 vlan172 10.10.50.0/24

*************************************
Creating third flat network
*************************************

# neutron net-create external4 -- --router:external  \
  --provider:network_type=flat \
  --provider:physical_network=physnet4

# neutron subnet-create --disable-dhcp external4 192.179.143.0/24


[root@ip-192-169-142-127 ~(keystone_admin)]# neutron net-show vlan157
+---------------------------+--------------------------------------+
| Field                     | Value                                |
+---------------------------+--------------------------------------+
| admin_state_up            | True                                 |
| availability_zone_hints   |                                      |
| availability_zones        | nova                                 |
| created_at                | 2016-05-05T11:04:57                  |
| description               |                                      |
| id                        | 98116982-6553-4b7e-920c-0284a7200916 |
| ipv4_address_scope        |                                      |
| ipv6_address_scope        |                                      |
| is_default                | False                                |
| mtu                       | 1500                                 |
| name                      | vlan157                              |
| provider:network_type     | vlan                                 |
| provider:physical_network | vlan157                              |
| provider:segmentation_id  | 157                                  |
| router:external           | True                                 |
| shared                    | True                                 |
| status                    | ACTIVE                               |
| subnets                   | d50fddd2-46e7-4c67-8ab5-97e952bc11c9 |
| tags                      |                                      |
| tenant_id                 | 5d0e67d2fe7a403180fe77232b0cdcd5     |
| updated_at                | 2016-05-05T11:04:57                  |
+---------------------------+--------------------------------------+

[root@ip-192-169-142-127 ~(keystone_admin)]# neutron subnet-show sub-vlan157
+-------------------+--------------------------------------------------+
| Field             | Value                                            |
+-------------------+--------------------------------------------------+
| allocation_pools  | {"start": "10.10.10.100", "end": "10.10.10.200"} |
| cidr              | 10.10.10.0/24                                    |
| created_at        | 2016-05-05T11:05:27                              |
| description       |                                                  |
| dns_nameservers   |                                                  |
| enable_dhcp       | True                                             |
| gateway_ip        | 10.10.10.1                                       |
| host_routes       |                                                  |
| id                | d50fddd2-46e7-4c67-8ab5-97e952bc11c9             |
| ip_version        | 4                                                |
| ipv6_address_mode |                                                  |
| ipv6_ra_mode      |                                                  |
| name              | sub-vlan157                                      |
| network_id        | 98116982-6553-4b7e-920c-0284a7200916             |
| subnetpool_id     |                                                  |
| tenant_id         | 5d0e67d2fe7a403180fe77232b0cdcd5                 |
| updated_at        | 2016-05-05T11:05:27                              |
+-------------------+--------------------------------------------------+

[root@ip-192-169-142-127 ~(keystone_admin)]# neutron net-show vlan172
+---------------------------+--------------------------------------+
| Field                     | Value                                |
+---------------------------+--------------------------------------+
| admin_state_up            | True                                 |
| availability_zone_hints   |                                      |
| availability_zones        | nova                                 |
| created_at                | 2016-05-05T11:05:46                  |
| description               |                                      |
| id                        | 6fc89f42-cb85-4cdb-be5f-4d1768b05e14 |
| ipv4_address_scope        |                                      |
| ipv6_address_scope        |                                      |
| is_default                | False                                |
| mtu                       | 1500                                 |
| name                      | vlan172                              |
| provider:network_type     | vlan                                 |
| provider:physical_network | vlan172                              |
| provider:segmentation_id  | 172                                  |
| router:external           | True                                 |
| shared                    | True                                 |
| status                    | ACTIVE                               |
| subnets                   | 2d4f907b-1f80-451a-a663-b87bbd683d58 |
| tags                      |                                      |
| tenant_id                 | 5d0e67d2fe7a403180fe77232b0cdcd5     |
| updated_at                | 2016-05-05T11:05:46                  |
+---------------------------+--------------------------------------+

[root@ip-192-169-142-127 ~(keystone_admin)]# neutron subnet-show sub-vlan172
+-------------------+--------------------------------------------------+
| Field             | Value                                            |
+-------------------+--------------------------------------------------+
| allocation_pools  | {"start": "10.10.50.100", "end": "10.10.50.200"} |
| cidr              | 10.10.50.0/24                                    |
| created_at        | 2016-05-05T11:10:18                              |
| description       |                                                  |
| dns_nameservers   |                                                  |
| enable_dhcp       | True                                             |
| gateway_ip        | 10.10.50.1                                       |
| host_routes       |                                                  |
| id                | 2d4f907b-1f80-451a-a663-b87bbd683d58             |
| ip_version        | 4                                                |
| ipv6_address_mode |                                                  |
| ipv6_ra_mode      |                                                  |
| name              | sub-vlan172                                      |
| network_id        | 6fc89f42-cb85-4cdb-be5f-4d1768b05e14             |
| subnetpool_id     |                                                  |
| tenant_id         | 5d0e67d2fe7a403180fe77232b0cdcd5                 |
| updated_at        | 2016-05-05T11:10:18                              |
+-------------------+--------------------------------------------------+

Enable EPEL 7 to install vconfig ( or use ip CLI )

***************************************************
Next Step - external bridges setup on Controller
***************************************************

# modprobe 8021q
# ovs-vsctl add-br br-vlan
# ovs-vsctl add-port br-vlan eth2
# vconfig add br-vlan 157

# ovs-vsctl add-br br-vlan2
# ovs-vsctl add-port br-vlan2 eth3
# vconfig add br-vlan2 172

**********************************
External flat network
**********************************

# ovs-vsctl add-br br-eth4
# ovs-vsctl add-port  br-eth4  eth4


****************************************************
Update Neutron OVS configuration files
****************************************************
Start with the following comment in l3_agent.ini:
# When external_network_bridge is set, each L3 agent can be associated
# with no more than one external network. This value should be set to the UUID
# of that external network. To allow L3 agent support multiple external
# networks, both the external_network_bridge and gateway_external_network_id
# must be left empty.
******************************
Update l3_agent.ini file
******************************
external_network_bridge =
gateway_external_network_id =

******************************************************
/etc/neutron/plugins/ml2/openvswitch_agent.ini
******************************************************
bridge_mappings = physnet1:br-eth1,vlan157:br-vlan,vlan172:br-vlan2,physnet4:br-eth4

*************************************
Update Neutron Configuration
*************************************

# openstack-service restart neutron

************************************************
Set up config persistent between reboots
************************************************

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-eth2
DEVICE="eth2"
ONBOOT=yes
OVS_BRIDGE=br-vlan
TYPE=OVSPort
DEVICETYPE="ovs"

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-eth3
DEVICE="eth3"
ONBOOT=yes
OVS_BRIDGE=br-vlan2
TYPE=OVSPort
DEVICETYPE="ovs"

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-br-vlan
DEVICE=br-vlan
BOOTPROTO=none
ONBOOT=yes
TYPE=OVSBridge
DEVICETYPE="ovs"

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-br-vlan2
DEVICE=br-vlan2
BOOTPROTO=none
ONBOOT=yes
TYPE=OVSBridge
DEVICETYPE="ovs"

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-br-vlan.157
BOOTPROTO="none"
DEVICE="br-vlan.157"
ONBOOT="yes"
IPADDR="10.10.10.150"
PREFIX="24"
GATEWAY="10.10.10.1"
DNS1="83.221.202.254"
VLAN=yes
NOZEROCONF=yes
USERCTL=no

[root@ip-192-169-142-127 network-scripts(keystone_admin)]# cat ifcfg-br-vlan2.172
BOOTPROTO="none"
DEVICE="br-vlan2.172"
ONBOOT="yes"
IPADDR="10.10.50.150"
PREFIX="24"
GATEWAY="10.10.50.1"
DNS1="83.221.202.254"
VLAN=yes
NOZEROCONF=yes

***************************
Then run script
***************************
#!/bin/bash -x
chkconfig network on
systemctl stop NetworkManager
systemctl disable NetworkManager
service network restart

# openstack-service restart neutron

[root@ip-192-169-142-127 ~(keystone_admin)]#  ip -details link show dev br-vlan.157
34: br-vlan.157@br-vlan: &lt;BROADCAST,MULTICAST,UP,LOWER_UP&gt; mtu 1500 qdisc noqueue state UP mode DEFAULT
    link/ether ba:bb:33:85:aa:49 brd ff:ff:ff:ff:ff:ff promiscuity 0
    vlan protocol 802.1Q id 157 &lt;REORDER_HDR&gt; addrgenmode eui64

[root@ip-192-169-142-127 ~(keystone_admin)]#  ip -details link show dev br-vlan2.172
33: br-vlan2.172@br-vlan2: &lt;BROADCAST,MULTICAST,UP,LOWER_UP&gt; mtu 1500 qdisc noqueue state UP mode DEFAULT
    link/ether 0e:e7:2d:26:c3:4a brd ff:ff:ff:ff:ff:ff promiscuity 0
    vlan protocol 802.1Q id 172 &lt;REORDER_HDR&gt; addrgenmode eui64

[root@ip-192-169-142-127 ~(keystone_admin)]# ip route
default via 10.10.10.1 dev br-vlan.157
10.10.10.0/24 dev br-vlan.157  proto kernel  scope link  src 10.10.10.150
10.10.50.0/24 dev br-vlan2.172  proto kernel  scope link  src 10.10.50.150
169.254.0.0/16 dev eth0  scope link  metric 1002
169.254.0.0/16 dev eth1  scope link  metric 1003
169.254.0.0/16 dev eth2  scope link  metric 1004
169.254.0.0/16 dev eth3  scope link  metric 1005
169.254.0.0/16 dev eth4  scope link  metric 1006
169.254.0.0/16 dev br-vlan  scope link  metric 1009
169.254.0.0/16 dev br-ex  scope link  metric 1010
169.254.0.0/16 dev br-vlan2  scope link  metric 1012
192.168.122.0/24 dev virbr0  proto kernel  scope link  src 192.168.122.1
192.169.142.0/24 dev br-ex  proto kernel  scope link  src 192.169.142.127

***************************
Controller/Network
***************************
[root@ip-192-169-142-127 ~(keystone_admin)]# ovs-vsctl show
d12e6a7a-f589-42cd-91b3-96156ad9ed59
    Bridge br-int
        fail_mode: secure
        Port "tap114497da-9f"
            tag: 1
            Interface "tap114497da-9f"
                type: internal
        Port "tap390b9bc5-b9"
            tag: 5
            Interface "tap390b9bc5-b9"
                type: internal
        Port "int-br-vlan2"
            Interface "int-br-vlan2"
                type: patch
                options: {peer="phy-br-vlan2"}
        Port "tap4b0c52b8-90"
            tag: 3
            Interface "tap4b0c52b8-90"
                type: internal
        Port "qr-795380c4-1d"
            tag: 2
            Interface "qr-795380c4-1d"
                type: internal
        Port "qg-b856b873-d0"
            tag: 3
            Interface "qg-b856b873-d0"
                type: internal
        Port "tap119f2a5f-2e"
            tag: 4
            Interface "tap119f2a5f-2e"
                type: internal
        Port int-br-vlan
            Interface int-br-vlan
                type: patch
                options: {peer=phy-br-vlan}
        Port "qr-2e2d2e81-14"
            tag: 1
            Interface "qr-2e2d2e81-14"
                type: internal
        Port "qg-234c2d9c-0a"
            tag: 4
            Interface "qg-234c2d9c-0a"
                type: internal
        Port "qr-41a1a0fa-ec"
            tag: 5
            Interface "qr-41a1a0fa-ec"
                type: internal
        Port br-int
            Interface br-int
                type: internal
        Port "qg-5c7b2d0a-1b"
            tag: 6
            Interface "qg-5c7b2d0a-1b"
                type: internal
        Port "int-br-eth4"
            Interface "int-br-eth4"
                type: patch
                options: {peer="phy-br-eth4"}
        Port "int-br-eth1"
            Interface "int-br-eth1"
                type: patch
                options: {peer="phy-br-eth1"}
        Port "tap936bd80d-26"
            tag: 2
            Interface "tap936bd80d-26"
                type: internal
    Bridge "br-vlan2"   <===external vlan172 network
        Port "eth3"
            Interface "eth3"
        Port "phy-br-vlan2"
            Interface "phy-br-vlan2"
                type: patch
                options: {peer="int-br-vlan2"}
        Port "br-vlan2"
            Interface "br-vlan2"
                type: internal
     Bridge "br-eth4"    <===external flat network
        Port "eth4"
            Interface "eth4"
        Port "phy-br-eth4"
            Interface "phy-br-eth4"
                type: patch
                options: {peer="int-br-eth4"}
        Port "br-eth4"
            Interface "br-eth4"
                type: internal

    Bridge br-ex
        Port br-ex
            Interface br-ex
                type: internal
        Port "eth0"
            Interface "eth0"
    Bridge "br-eth1"        <=== internal vlan enabled vm/data network
        Port "phy-br-eth1"
            Interface "phy-br-eth1"
                type: patch
                options: {peer="int-br-eth1"}
        Port "eth1"
            Interface "eth1"
        Port "br-eth1"
            Interface "br-eth1"
                type: internal
    Bridge br-vlan    <===external vlan157 network
        Port br-vlan
            Interface br-vlan
                type: internal
        Port "eth2"
            Interface "eth2"
        Port phy-br-vlan
            Interface phy-br-vlan
                type: patch
                options: {peer=int-br-vlan}
    ovs_version: "2.4.0"
[root@ip-192-169-142-127 ~(keystone_admin)]# ifconfig
br-ex: flags=4163  mtu 1500
        inet 192.169.142.127  netmask 255.255.255.0  broadcast 192.169.142.255
        inet6 fe80::3058:e2ff:fe5c:f64c  prefixlen 64  scopeid 0x20
        ether 32:58:e2:5c:f6:4c  txqueuelen 0  (Ethernet)
        RX packets 54754  bytes 12112793 (11.5 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 48647  bytes 15788730 (15.0 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

br-vlan: flags=4163  mtu 1500
        inet6 fe80::2054:9fff:feb5:b645  prefixlen 64  scopeid 0x20
        ether 22:54:9f:b5:b6:45  txqueuelen 0  (Ethernet)
        RX packets 51  bytes 6647 (6.4 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 298  bytes 16763 (16.3 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

br-vlan2: flags=4163  mtu 1500
        inet6 fe80::149a:c9ff:fe29:2240  prefixlen 64  scopeid 0x20
        ether 16:9a:c9:29:22:40  txqueuelen 0  (Ethernet)
        RX packets 497  bytes 24405 (23.8 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 31  bytes 4481 (4.3 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

br-vlan.157: flags=4163  mtu 1500
        inet 10.10.10.150  netmask 255.255.255.0  broadcast 10.10.10.255
        inet6 fe80::2054:9fff:feb5:b645  prefixlen 64  scopeid 0x20
        ether 22:54:9f:b5:b6:45  txqueuelen 0  (Ethernet)
        RX packets 34  bytes 4667 (4.5 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 290  bytes 14955 (14.6 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

br-vlan2.172: flags=4163  mtu 1500
        inet 10.10.50.150  netmask 255.255.255.0  broadcast 10.10.50.255
        inet6 fe80::149a:c9ff:fe29:2240  prefixlen 64  scopeid 0x20
        ether 16:9a:c9:29:22:40  txqueuelen 0  (Ethernet)
        RX packets 480  bytes 16181 (15.8 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 23  bytes 3741 (3.6 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth0: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fe82:e40e  prefixlen 64  scopeid 0x20
        ether 52:54:00:82:e4:0e  txqueuelen 1000  (Ethernet)
        RX packets 56233  bytes 12189701 (11.6 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 48639  bytes 15786905 (15.0 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1: flags=4163  mtu 1500
        inet6 fe80::5054:ff:feb2:82c  prefixlen 64  scopeid 0x20
        ether 52:54:00:b2:08:2c  txqueuelen 1000  (Ethernet)
        RX packets 4327  bytes 2918115 (2.7 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1882  bytes 6415333 (6.1 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth2: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fec9:cdcf  prefixlen 64  scopeid 0x20
        ether 52:54:00:c9:cd:cf  txqueuelen 1000  (Ethernet)
        RX packets 3334  bytes 6491253 (6.1 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 3064  bytes 2816873 (2.6 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth3: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fe48:266f  prefixlen 64  scopeid 0x20
        ether 52:54:00:48:26:6f  txqueuelen 1000  (Ethernet)
        RX packets 2027  bytes 108290 (105.7 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 88  bytes 43478 (42.4 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth4: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fe92:f712  prefixlen 64  scopeid 0x20
        ether 52:54:00:92:f7:12  txqueuelen 1000  (Ethernet)
        RX packets 1489  bytes 77816 (75.9 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 9  bytes 718 (718.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 422071  bytes 134700542 (128.4 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 422071  bytes 134700542 (128.4 MiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

virbr0: flags=4099  mtu 1500
        inet 192.168.122.1  netmask 255.255.255.0  broadcast 192.168.122.255
        ether 52:54:00:e9:36:be  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0


******************************************************************************************
Verification VLAN connectivity from WKS (VM) having eth1.157 &amp;&amp; eth2.172 to mentioned bellow Java Servers running on Compute Node 192.169.142.137 as Nova-Docker Containers (instances)  with floating ips on vlan157 and  vlan172 correspondently
******************************************************************************************
Network configuration on WKS

[root@VlanConnect ~]# ifconfig
eth0: flags=4163  mtu 1500
        inet 192.169.142.45  netmask 255.255.255.0  broadcast 192.169.142.255
        inet6 fe80::5054:ff:fef5:a7eb  prefixlen 64  scopeid 0x20
        ether 52:54:00:f5:a7:eb  txqueuelen 1000  (Ethernet)
        RX packets 3358  bytes 178671 (174.4 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 22  bytes 3676 (3.5 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fe2e:716c  prefixlen 64  scopeid 0x20
        ether 52:54:00:2e:71:6c  txqueuelen 1000  (Ethernet)
        RX packets 5154  bytes 1994070 (1.9 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1157  bytes 153055 (149.4 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth2: flags=4163  mtu 1500
        inet6 fe80::5054:ff:fe62:5abb  prefixlen 64  scopeid 0x20
        ether 52:54:00:62:5a:bb  txqueuelen 1000  (Ethernet)
        RX packets 3384  bytes 213816 (208.8 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 654  bytes 36212 (35.3 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eth1.157: flags=4163  mtu 1500
        inet 10.10.10.45  netmask 255.255.255.0  broadcast 10.10.10.255
        inet6 fe80::5054:ff:fe2e:716c  prefixlen 64  scopeid 0x20
        ether 52:54:00:2e:71:6c  txqueuelen 0  (Ethernet)
        RX packets 1823  bytes 1786566 (1.7 MiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1151  bytes 147974 (144.5 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0


eth2.172: flags=4163  mtu 1500
        inet 10.10.50.45  netmask 255.255.255.0  broadcast 10.10.50.255
        inet6 fe80::5054:ff:fe62:5abb  prefixlen 64  scopeid 0x20
        ether 52:54:00:62:5a:bb  txqueuelen 0  (Ethernet)
        RX packets 52  bytes 38138 (37.2 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 647  bytes 33022 (32.2 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

lo: flags=73  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10
        loop  txqueuelen 0  (Local Loopback)
        RX packets 590  bytes 62280 (60.8 KiB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 590  bytes 62280 (60.8 KiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

virbr0: flags=4099  mtu 1500
        inet 192.168.122.1  netmask 255.255.255.0  broadcast 192.168.122.255
        ether 52:54:00:13:11:69  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0


[root@VlanConnect ~]# ip -details link show dev eth1.157
5: eth1.157@eth1: mtu 1500 qdisc noqueue state UP mode DEFAULT
    link/ether 52:54:00:2e:71:6c brd ff:ff:ff:ff:ff:ff promiscuity 0
    vlan protocol 802.1Q id 157 addrgenmode eui64


[root@VlanConnect ~]# ip -details link show dev eth2.172
6: eth2.172@eth2: mtu 1500 qdisc noqueue state UP mode DEFAULT
    link/ether 52:54:00:62:5a:bb brd ff:ff:ff:ff:ff:ff promiscuity 0
    vlan protocol 802.1Q id 172 addrgenmode eui64

********************************************************************************
Attempt to launch browser to GlassFish 4.X and Tomcat 7.0 consoles
********************************************************************************

Nova-Docker instance derbyGlassfish01 on vlan157 (10.10.10.105:4848)
Nova-Docker instance  Tomcat  on vlan172  (10.10.50.105:8080)
